Johnson Controls VG7243NT+822C00 3-Way Mixing Valve Actuator Assembly

Specifications

• Manufacturer: Johnson Controls • Model / Part Number: VG7243NT+822C00 • Type: 3-Way Mixing Control Valve with Electric Actuator • Valve Size: 1-1/2 inch (DN40) • Flow Coefficient (Cv): 25.0 • Body Material: Bronze • Connection Type: NPT (National Pipe Thread) • Actuator: M9220 Series Electric Actuator (included) • Power Supply: 24 VAC • Control Signal: Proportional (0–10 VDC or 4–20 mA, depending on actuator configuration) • Maximum Pressure: 250 psi (bronze body rating) • Applications: HVAC water systems, heating/cooling coils, mixing or diverting flow control
