Honeywell TrueZONE ZD24x10TZ 24in x 10in Parallel Blade Zone Damper

Specifications

Electrical HVAC Thermostats Thermostat Wire Tools Plumbing Honeywell TrueZONE ZD24x10TZ 24in x 10in Parallel Blade Zone Damper ZD24X10TZ - TRUEZONE 24"X10" side mount RECTANGULAR DAMPER W/ 24V ACTUATOR The ZD Series Damper is a power close and spring open damper. It has a 24- volt motor used to control circulating air in HVAC systems and used when a normally-open damper is required. The ZD is typically used with the TrueZONE and other electronic zoning systems. TrueZONE Damper Product Features: • Direct replacement for todays Honeywell legacy dampers • Easier installation and troubleshooting • Improved motor and gearing to insure long life and reliable operation • 2 position, 24 Vac power close, spring return forced air zoning damper • Adjustable range stops that are simple to use • Mechanical position indicator for damper blade • LED indicators show operation • Push-in terminals that are the same as the Honeywell TrueZONE panel • Quieter operation • With R-8 insulation compatibility, the TrueZone damper is designed to pass energy efficiency audits. Product Details Color Height 32.000 Length 10.375 UPC 085267769884 HVACSurplus.com works with a wide variety of brands that you know & trust. Some of our brands include: Aprilaire ∙ Belimo ∙ Braeburn ∙ CPS Products ∙ DiversiTech ∙ Ecobee ∙ Emerson ∙ Functional Devices ∙ GeneralAire ∙ Honeywell ∙ ICM Controls ∙ iO HVAC Controls ∙ Jackson Systems ∙ Johnson Controls ∙ Kidde ∙ LeakSmart ∙ Little Giant ∙ Lux ∙ Malco ∙ MA-Line ∙ NAVAC ∙ Nest ∙ Packard ∙ Peco ∙ Pro1 IAQ ∙ Ranco ∙ Rectorseal ∙ Resideo ∙ Ring ∙ Robertshaw ∙ SolderWeld ∙ Skytech ∙ Supco ∙ UEI Test Instruments ∙ Universal Secruity Instruments ∙ Vents US ∙ White-Rodgers
