DAYTON 1C791 Blower,6 5/16 In, Less Motor 1C791

Specifications

Blower, Wheel Type Forward-Curved, Drive Type Direct Drive, Assembly Unassembled, Wheel Diameter 6 1/4 in, Maximum Airflow 595 cfm, Maximum Static Pressure 3/4 in wc, Maximum Inlet Air Temperature 180 Degrees F, Wheel Material Steel, Housing Material Steel, Wheel Width 2 1/2 in, Number of Inlets 1, Inlet Diameter 6 in, Outlet Shape Rectangular, Outlet Height 7 3/8 in, Outlet Width 4 1/4 in, Outlet Diameter Not Applicable, Flange Type Non-Flanged, Maximum Motor Horsepower 1/4 hp Single-Inlet Forward Curve Direct-Drive Blowers • Housing can be rotated to 8 discharge positions in each rotation Welded steel construction Gray baked-on epoxy finish Max. inlet air temp.: 180 Degrees F Max. ambient temp.: 104 Degrees FProvide high-volume ventilation when duct systems are required. Motor packed.
